IP camera DS-2CD2D25G1/M-D/NF 2.8mm 2MP Mini white

SKU: 311318330

2CD2D25DWDM-12--

IP camera Hikvision DS-2CD2D25G1/M-D/NF(2.8mm), 2 MP Mini H.265+, 120dB WDR, 3D DNR, RJ45, 12VDC

Retail price:

€ 204.03

€ 167.24 + VAT

In stock

Tallinn: 6 psc.

Tartu: Sold Out

Central Tallinn: Sold Out

Latvia: 2 psc

High quality imaging with 2 MP resolution
Efficient H.265+ compression technology to save bandwidth and storage
Clear imaging against strong back light due to 120 dB true WDR technology
3D DNR technology delivers clean and sharp images

Base Attributes

Brand	Hikvision
Net Weight	0.1
Gross Weight	0.241

Key Parameter

Case type	Cube
Resolution	2 MP
Lens Type	Fixed Lens
Low-Light Imaging	Normal
Illumination Distance	N/A, N/A
Wireless Network	N/A
Storage Type	N/A
AI	N/A
Local Output	N/A

Camera

Image Sensor	1/2.8" Progressive Scan CMOS
Min. Illumination	Color: 0.002 Lux @ (F1.2, AGC ON)

Camera Module

WDR	120 dB

Lens

Focal Length & FOV	2.8 mm: horizontal FOV: 107.8°, vertical FOV: 57.9°, diagonal FOV: 126.7° 4 mm: horizontal FOV: 82.8°, vertical FOV: 45.1°, diagonal FOV: 98°
Iris Type	Fixed

Video

Main Stream	50 Hz: 50 fps (1920 × 1080, 1280 × 720) 60 Hz: 60 fps (1920 × 1080, 1280 × 720)
Bit Rate Control	CVR/BVR

Network

Simultaneous Live View	Up to 15 channels
Protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
User/Host	Up to 32 users 3 level: administrator, operator, and user
Client	iVMS-4200, Hik-Connect


Day/Night Switch	Day, Night, Auto, Schedule

Interface

Audio	1 input (line in)

Event

Basic Event	Motion detection, video tampering alarm, exception (HDD full, HDD error, network disconncected), video quality diagnosis
Smart Event	Intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection Audio exception detection, defocus detection, scene change detection

General

General Function	One-key reset, heartbeat, mirror, password protection, privacy mask, rotate, watermark, IP address filter
Storage Conditions	-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Power Supply	12 VDC
Startup and Operating Conditions	-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Dimension	31.5 mm × 31.5 mm × 49.6 mm (1.2" × 1.2" × 2")

Approval

Safety	UL (UL 62368-1); CB (IEC 62368-1:2014+A11); CE-LVD (EN 62368-1:2014/A11:2017); BIS (IS 13252(Part 1):2010/ IEC 60950-1 : 2005); LOA (IEC/EN 60950-1)
