Kuumakse al. Kirjeldus
| Specification | FMC 10 (50m) | FMC 10 (100m) | FMC 10 (200m) |
| Operational frequency | 10.425-10.625 GHz | ||
| Range | 5…50 m | 10…100 m | 10…200m |
| Width of the detection zone | 0,8…2 m | 1…3 m | 1…4 m |
| Height of the detection zone | 0,8…1,4 m | 1…1,6 m | 1…1,8 m |
| Supply voltage | 9…30 V DC | ||
| Current consumption | 45 mA (Tx 10 mA, Rx 35 mA) | ||
| Detection probably | not less than 0,98 | ||
| Operational temperature | minus 40…+65°C | ||
| Housing protection level | IP-55 | ||
| Alarm output | NC relay contacts (100 Ohm) | ||
| Interfaces | RS-485, Bluetooth (using RS-BL conventer) | ||
| Dimensions | 207x133x50 mm | ||
| Channels | 4 independent channels | ||
